Motorized control valves work to control flow by both opening and closing an opening inside a pipeline. When the valve is open, fluid is able to bypass through freely. When the valve is closed, liquid flow is closed and prevented from incoming that section of pipe. It is necessary that motorized control valves are ordered in the suitable size for a system application, as this allows for them to make a dependable fasten that liquids cannot go through. Accessories: Modulating Controller 4 ~ 20 mA (Available on request) Potentiometer Feedback (Available on request) Integral Starter unit (Available on request) Control Panel (Available on request)
Price as per Requirement
Vendor Details
Standard Hardware
RUTUBH PATEL
.png)
0 /5
(0 ratings)
Annual Turnover : Rs. 5 Crore
Area of Expertise : Industrial Hardware
Product Specifications
Travel: |
Linear |
Indicator: |
Continuous Position Indicator |
Phase: |
Single Phase |
Power Supply: |
220V AC, 50 Hz |
Body Material: |
Aluminum Alloy |
Ambient Temperature: |
20° C ~ 80° C |
Motor Insulation: |
Class F |
Protection Class: |
IP 67 – Weather Proof |
Limit Switches: |
1No + 1Nc Output of 220V AC |
Position on Power Fail: |
Stay Put |
Manual Override: |
Wheel Type |
Characteristic: |
On – Off Type |
