MJ Series pumps are fluoropolymer lined, magnetic drive, horizontal, single stage, volute casing, center line discharge, end suction, sealless centrifugal pumps with rotary shaft design to surpass performance expectations in the most demanding chemical applications and environments.
Price as per Requirement
Vendor Details
Chem Pump and Equipments
Nimish Kothari
.png)
0 /5
(0 ratings)
Annual Turnover : Rs. 15 Crore
Area of Expertise : Pumps - Metallic, Non-metallic, AODD, Thermic Fluid; Valves, Filtration Units, Priming Chamber
Product Specifications
Minimum Continuous Flow [MCF]: |
2.5 m3 /hr (11 US gpm) |
Suction & Delivery Connection: |
ANSI B16.5, DIN2501, BS4504-PN16 |
Capacity [Q] up to: |
440 US gpm (100 m3 /hr |
Operating Frequency: |
60 Hz |
Maximum Temp: |
PFA (180°C), PVDF (104°C) |
Head [H] up to: |
282 ft (86 m) |
Motor Power [P] up to: |
30 hp (22 kW) |
Viscosity up to: |
150 mPas (cP) |
Suction Lift: |
4 m (13 ft) with priming chamber* |
Maximum Working Pressure: |
16 bar (232 psi) |
Maximum Specific Gravity [SG]: |
1.8 - 3 |
